You want to add a Baseline Camera to your Wingfield Box? Here you will find all basic information about the camera and the installation.
๐Here you are in the installation process of the Baseline Camera.
- 1๏ธโฃ Technical Specs and Scope of Delivery
- 2๏ธโฃ Wiring the Baseline Camera
- 3๏ธโฃ Baseline Camera Configuration
- 4๏ธโฃ Mounting the Baseline Camera
Technical specs โ๏ธ
Measures |
20x20cm |
Weight | 2,6kg |
Material | Aluminium, synthetic material |
Connections | The camera is connected via LAN cable (CAT6a or better) to the PoE-switch and thus directly supplied with power. |
Video quality | Recordings are uploaded in 720p to ensure a faster upload. |
Sound | The Baseline Camera has an integrated shotgun microphone. |
Resilience | Outdoor-ready and weather-resistant. |
Scope of delivery ๐ฆ
Wingfield Baseline Camera
Wingfield Baseline Camera Incl. mounting plate |
![]()
|
1x Mounting kit Baseline Camera for mounting the Baseline Camera on fences, poles, beams and walls. |
![]()
|
Outdoor LAN Set 40m outdoor LAN cable, incl. protective caps for winter and waterproof connector for extra long distances.
|
![]() |
โ๐ผ By the way: Since the conditions are different at each court, we have assembled various mounting options for you. For example, you can mount the camera directly on the wall or a fence post with our pole mounts.
Outdoor PoE-switch
Premium PoE-switch 5x RJ45 slots (1x occupied by power supply) with PoE 802.3 af. |
![]()
|
Outdoor housing Protection and power supply for the PoE switch. |
![]()
|
Mounting kit PoE-switch To easily mount the switch inside the Wingfield Box housing. |
![]()
|
Special power cable (1m) Waterproof connection of the switch (orange).
|
![]() |
๐กTip: The PoE switch connects your Wingfield Box to your Baseline Camera. In order to reduce the cabling at the court to a minimum, we recommend mounting the switch inside the Wingfield Box housing.
Installation Guide๐ง
Now that you have an overview, we will guide you through the installation of your Baseline Camera:
- 1๏ธโฃ Technical Specs and Scope of Delivery โ๏ธ
- 2๏ธโฃ Wiring the Baseline Camera
- 3๏ธโฃ Baseline Camera Configuration
- 4๏ธโฃ Mounting the Baseline Camera
โก๏ธ Continue with step 2: Wiring the Baseline Camera
